8 channels AHD/CVI/TVI over fiber converter (1080P) with 1ch RS485 data

Model:CHD0801-1080

Support 8 channels AHD/CVI/TVI with 1-port RS485,1080P;
Lossless non-compression real time transmission;
CWDM technology offer 3.2G bandwidth to 8ch video;
Automatically identify AHD/TVI/CVI/PAL/NTSC/SECAM formats ;
Support 720P/25/30/50Hz, 960P/25/30Hz,1080P/30Hz;
Support 5.7KV lightning protection;
Wide range of operational temperature(-15 °C ~65°C);
Compatible with AHD/CVI/TVI Cameras;
Warranty: 3 years

REQUEST A QUOTE

Introduction

CHD0801-1080 supports 8-Ch TVI/CVI/AHD TO Fiber Converters is universal type supporting High Definition Analog video format HD-TVI / HD-CVI / AHD, can simultaneously transmit 8 channels video with 1-port RS485 over one core multimode or single-mode optical fiber. It also supports the regular analog video format such as PAL / NTSC /SECAM, it is a kind of universal fiber transmission solution/product for CCTV analog video/data signals.



Devices are available for either standalone or rack-mount installation, which is suitable for different working environment. Electronic and optical adjustments are never required. LED indicators are provided for instantly monitoring system status.
